Extreme Recovery Towbar And Wiring Kit For LDV T60 & T60 Max Styleside Tub (03/2024 - On) by TAG
This TAG Extreme Recovery (XR) Towbar and wiring kit suits LDV T60 and T60 Max Styleside tub models with a rear step, from the 03/2024 model update onward. The towbar is the same Australian-built, ADR compliant unit used across the T60 range, rated to 3500kg towing capacity and 350kg ball weight, paired here with a direct-fit wiring harness for trailer or caravan lights.
Two WLL 4000kg load-rated recovery points are built into the towbar's 3-piece side-arm design, a genuine rated recovery point rather than a standard tow ball. One thing worth checking before you order: the wiring harness in this kit is built for the 10-way pre-wire connector fitted to 04/2024-on models. If your T60 has the 8-way connector, you'll need TAG's universal wiring instead.
Kit includes the towbar, TAG's direct-fit wiring harness and a 7 pin flat socket on the vehicle side.
Features
- Extreme Duty Reinforced Crossbar
- Two WLL 4000kg load-rated recovery points with bevelled edges suited to soft-shackles
- Flush chassis-mounted profile for improved departure angles and offroad clearance
- Textured powder coated finish
- Dual top-mounted trailer and Anderson plug mounts
- Class 4 towbar with 50mm square hitch receiver
- TAG Limited Lifetime Warranty
Wiring note: this harness only suits 04/2024-on models fitted with the 10-way pre-wire connector. For 04/2024-on models with the 8-way connector, use TAG's universal wiring instead.
A towbar is a safety-critical item and fitment can vary between vehicles even within the same model. We recommend having your towbar and wiring harness installed by a professional towbar or vehicle accessory fitting workshop.
Towbar Specifications
- Towbar Class: Heavy Duty (4x4 Recovery)
- Towbar Capacity [kg]: 3500
- Ball Weight [kg]: 350
- Recovery Load-tested: 4000kg WLL
- Recovery Points: 2
- Hitch Type: 50mm Square Hitch Receiver
- Tow Ball Mount: L4045TXR
- Coating: Textured Powder Coated
- Exposure: Partially concealed
- Bumper Removed During Fitment: Yes
- Bumper Cut Out Required: No
- Fitting Time [min.]: 60
Wiring Specifications
- Wiring Option: Direct Fit ECU
- Wiring Type: Direct Fit
- Diagnostic Coding: No
- LED Support: yes
- Reverse Sensor Cut Off: Optional
What's Included
- TAG 4x4 Recovery Towbar
- TAG Direct Fit Wiring Harness
- TAG 7 Pin Flat Socket (Vehicle Side)
Documentation
Only need the towbar, not the wiring? See the towbar-only version.
Vehicle Applications
This towbar and wiring kit is listed against the following 10 vehicle records on the supplier's fitment guide. Always confirm exact fitment for your specific vehicle before ordering.
| Make |
Model |
From |
To |
Body |
Series |
Engine |
Variant |
Drivetrain |
| LDV |
T60 |
03/2024 |
- |
Ute |
SK8C |
0.0L | Electric |
– |
RWD |
| LDV |
T60 |
03/2024 |
- |
Ute |
SK8C |
SC20M218Q5 | 2.0L | Diesel |
DTT |
AWD |
| LDV |
T60 |
03/2024 |
- |
Ute |
SK8C |
SC20M218Q5 | 2.0L | Diesel |
DTT |
RWD |
| LDV |
T60 |
03/2024 |
- |
Ute |
SK8C |
SC20M163Q5 | 2.0L | Diesel |
– |
AWD |
| LDV |
T60 |
03/2024 |
- |
Ute |
SK8C |
SC20M163Q5 | 2.0L | Diesel |
– |
RWD |
| LDV |
T60 |
03/2024 |
- |
Ute |
– |
D20 | 2.0L | Diesel |
TRAILRIDER 2 |
Automatic/Manual 4WD |
| LDV |
T60 |
03/2024 |
- |
Ute |
– |
SC28R150Q5 | 2.8L | Diesel |
LUXE, PRO, TRAILRIDER, |
Automatic/Manual 4WD |
| LDV |
T60 |
03/2024 |
- |
Ute |
– |
SC28R150Q5 | 2.8L | Diesel |
Pro| Luxe |
4WD |
| LDV |
T60 |
03/2024 |
- |
Ute |
SK8C |
SC28R150Q5 | 2.8L | Diesel |
– |
RWD |
| LDV |
T60 |
03/2024 |
08/2021 |
Ute |
SK8C |
SC28R150Q5 | 2.8L | Diesel |
– |
AWD |
Frequently Asked Questions
What's included in this kit?
The kit includes the TAG 4x4 Recovery Towbar, TAG's direct-fit wiring harness and a 7 pin flat socket on the vehicle side.
Which wiring connector does this kit suit?
The wiring harness in this kit suits 04/2024-on models fitted with the 10-way pre-wire connector. If your T60 has the 8-way connector instead, use TAG's universal wiring rather than this direct-fit harness. Check your vehicle's connector before ordering if you're unsure which one you have.
Does this towbar include a wiring harness?
Yes, this kit includes both the towbar and a direct-fit wiring harness. If you only need the towbar, see the towbar-only version.
Is professional installation recommended?
Yes. A towbar and wiring harness are safety-critical items, and fitment can vary between vehicles even within the same model. We recommend installation by a professional towbar or vehicle accessory fitting workshop.
What's the towing and recovery rating of the towbar in this kit?
The towbar is rated to 3500kg towing capacity and 350kg ball weight, with two WLL 4000kg load-rated recovery points.
Does fitting this towbar require removing the rear bumper?
Yes, the rear bumper is removed during fitment on the Styleside. No bumper cut-out is required.
Is this towbar rated as a recovery point?
Yes. It has two WLL 4000kg load-rated recovery points built into the side-arms, with bevelled edges suited to soft-shackles, a genuine rated recovery point rather than a standard tow ball.
Do I need to tell my insurer I've fitted a towbar?
Check with your insurer and your state's transport authority, as requirements vary. Some insurers ask you to declare towing accessories, particularly if you plan to tow regularly.
