San Hima Kalbarri X Hardshell Roof Top Tent with Ladder + Solar Panel - 130W Solar Panel

San Hima Kalbarri X Hardshell Roof Top Tent with Ladder + Solar Panel

San Hima Kalbarri X Hardshell Roof Top Tent with Ladder + Solar Panel - 200W Solar Panel

San Hima Kalbarri X Hardshell Roof Top Tent with Ladder + Solar Panel

by San Hima

SKU SH-RTT-UP+VASPZHI-3H-SUN

$3,398.00 - $3,528.00

$3,478.00

$3,398.00 - $3,528.00

$3,478.00

Quantity

4x4 Down Under Buy Now Pay Later Options

Why Shop With Us?

Fast Shipping with Free Insurance i Dispatched quickly from Australian warehouses, with every order covered by free transit insurance until it reaches your door.
Australian Owned and Operated i A family run Aussie business since 2016, based on the Sunshine Coast QLD. Local knowledge, local support.
Expert Before & After Sales Service i Not sure what fits your rig? Call, SMS or email us. Real 4WDers who know the gear, before and after you buy.
Easy Returns & Full Warranty Support i Quick and simple returns with no mess and no fuss, plus full manufacturer warranty support handled locally.

Kalbarri X Hardshell Roof Top Tent with Ladder and 130W, 200W or 250W Solar Panel by San Hima

The Kalbarri X paired with a solar panel is the version of this tent that suits people who stay put for a few days. You get the X-arm hardshell, which lifts the rear of the tent so you can sit up at the foot of the bed, and a matched San Hima panel with its charge controller so the battery keeps up with the fridge.

The tent itself is unchanged from the standalone Kalbarri X. A 201 x 125cm sleeping area with 138.5cm of headroom, a 5cm non-deformable memory foam mattress over an anti-condensation mat, and four separate openings, dual side windows with mesh rain flies, a ceiling window and a lower window, that move air through the tent instead of around it.

Build is 420D double ripstop Oxford and 280GT poly-cotton at PU 5,000mm and UV 50+, on an aluminium honeycomb base with a 3cm elevated edge. Panel choice runs 130W at 8.2kg through to 250W at 14.51kg, all monocrystalline. It sits at the top of the Kalbarri range in our roof top tents line-up.

Features

X-arm elevation. Extra rear headroom and more natural light.
Four-point ventilation. Dual side windows with mesh rain flies, a ceiling window and a lower window.
420D double ripstop Oxford and 280GT poly-cotton. PU 5,000mm waterproof rating with UV 50+ protection.
3cm elevated base. Raised floor edge against water intrusion.
5cm non-deformable memory foam mattress. Plush suede surface over an anti-condensation mat.
201 x 125cm sleeping area with 138.5cm interior height.
Side and top pockets plus a sliding shoe pocket.
Integrated crossbars rated to 20kg. The X-arm exterior is shaped to prevent snags, and recessed slots simplify screw insertion.
Telescopic ladder to 2.3m, 150kg capacity. Hooks on three sides.
Built-in LED light.
Matched solar panel and charge controller included. 130W, 200W or 250W monocrystalline.

Note: dry the tent thoroughly after each use, avoid damp storage, and ventilate it regularly if unused for long periods.

Specifications

Colour: Cloud Grey
Body: 420D Double Ripstop Oxford Fabric & 280GT Polyester-Cotton
Waterproof: PU 5000mm
UV Protection: 50+
Telescopic Ladder: Aluminium
Base Material: Aluminium Honeycomb Panel
Base Frame: Aluminium Alloy
Cloud Foam Mattress: 199 x 120 x 5cm
Tent Size (Folded): 215 x 136 x 17cm
Tent Size (Unfolded): 215 x 136 x 153cm
Internal Size: 201 x 125 x 138.5cm
Maximum Capacity & Length (Ladder): 150kg; 2.3m (Fully Extended)
Maximum Crossbar Load Rating: 20kg
Gas Strut Rating: 600 Newtons
Product Weight: 88.5kg
Package Size: 2325mm x 1490mm x 250mm

Solar Panel Specifications

Solar Panel	130W	200W	250W
Max Power	130W	200W	250W
Open-Circuit Voltage	22.5V	25.7V	22.3V
Short-Circuit Current	7.55A	9.95A	15.10A
Max Power Voltage	18.3V	21.5V	18.2V
Max Power Current	7.10A	9.31A	13.74A
Maximum System Voltage	1000 VDC	–	1000 VDC
Temperature Range	-40°C to +85°C	-40°C to +85°C	-40°C to +85°C
Solar Cell	Mono	–	–
Product Dimension (L x W x H)	920 x 30 x 670 mm	1476 x 35 x 670 mm	1580 x 808 x 35 mm
Gross Weight	8.2 kg	10.6 kg	14.51 kg

What's Included

1 x San Hima Kalbarri X Rooftop Tent
1 x Solar Panel Kit | 130W / 200W / 250W
1 x Solar Charge Controller
1 x Telescopic Ladder
1 x Telescopic Ladder Storage Bag
4 x Window Rods
2 x Crossbars
1 x LED Strip Light & 1 x LED Strip Light Adapter
1 x Repair Accessories
4 x Lock Keys
1 x User Manual
Set of Mounting Kit

Warranty

2 Year Manufacturer Warranty for the Roof Top Tent
12 Month Manufacturer Warranty for the Solar Panel

User Manual

San Hima Kalbarri X Rooftop Tent Hardshell User Manual

Frequently Asked Questions

Can my vehicle take the Kalbarri X with a solar panel?

The tent is 88.5kg before roof bars, and the panel adds 8.2kg to 14.51kg on top. That makes this one of the heavier setups in the range, so your vehicle's dynamic roof load rating is the figure to check, not the static rating. Add tent, panel, bars and anything else on the roof, then compare against your handbook. Where it is marginal, confirm with the vehicle manufacturer or a licensed mechanic before fitting.

Which panel suits a fridge and a couple of devices?

The three options are 130W at 8.2kg, 200W at 10.6kg and 250W at 14.51kg, all monocrystalline and all supplied with a charge controller. The larger panels give you more headroom on overcast days, at the cost of more to carry and stow. Your battery capacity and daily draw decide it, so work from what your fridge actually pulls.

What does the X-arm design change compared to a standard hardshell?

It lifts the rear section, which gives you usable headroom at the foot of the bed rather than only at the entry end, and lets more natural light in. The exterior arm is shaped to prevent snags on the fabric.

How is the ventilation different in the Kalbarri X?

Four openings instead of two: dual side windows with mesh rain flies, a ceiling window and a lower window. Because they sit at different heights, air crosses the tent rather than sitting in it, which is what keeps condensation down.

Who should wire the solar side?

The kit includes the panel and a charge controller. We recommend the 12V connection be made by a qualified auto electrician unless you are confident with vehicle electrical work, and that you follow the manufacturer's instructions for the controller.

What can I put on the crossbars?

They are rated to a maximum of 20kg. That limit sits inside your vehicle's roof load rating rather than adding to it, so anything up there counts against both figures.

How does the Kalbarri X Solar bundle pack down?

Folded, the tent is 215 x 136 x 17cm, and the panel stows separately at between 920 x 30 x 670mm and 1580 x 808 x 35mm depending on size. Check your garage or carport clearance against the tent height plus your bars and roof.

What is included for repairs?

A repair accessories pack, four window rods, two crossbars, four lock keys, the mounting kit, the ladder and its storage bag, and the LED strip light with adapter.
