Safari Snorkel Kit Designed for Mazda BT-50 (11/2011 - 12/2019) | SS985HF

Upgrade your Mazda BT-50 (11/2011 - 12/2019) with the Safari SS985HF Snorkel Kit, tailored to enhance the performance and durability of your 4x4. This snorkel kit is specifically designed for the 08/2011 Onwards 3.2L Diesel engines, offering a significant improvement in air intake quality and engine protection.

The Safari snorkel system is engineered to meet the high air flow demands of the Mazda 3.2L BT-50 engines from August 2011 onwards. By elevating the air intake, the snorkel prevents harmful elements like dust and water from entering the vehicle's air cleaner, crucial for maintaining optimal engine health, especially in challenging environments.

A key feature of this snorkel kit is the Safari air ram. It serves a dual purpose: not only does it channel cool, clean air into the engine, but it also acts as an efficient water separator. This design ensures that rainwater is removed from the incoming air, protecting the engine during heavy rain and tropical storms.

Constructed from durable, UV stable, cross-linked polyethylene material, the genuine Safari Mazda BT-50 4x4 Snorkel body and air ram are built to the highest standards. The thickness and quality of the material provide immense physical strength, enabling the snorkel to withstand even the most rigorous off-road conditions.

Key Features of the Safari Mazda BT-50 4x4 Snorkel

  • Australian Engineering: Safari Automotive's Australian-designed, moulded, and manufactured product.
  • Elevated Air Intake: Protects the engine from ingesting harmful elements.
  • Optimised Airflow: Enhances airflow to the 3.2L Diesel engine for improved performance.
  • Water Separation: Air ram design that removes water from the air stream.
  • Durability: Robust and UV-resistant snorkel and air ram for extended strength.
  • Installation Guide: Includes a comprehensive fitting guide and precise template for straightforward installation.
Safari V-Spec snorkels are the traditional Safari Snorkel range.
  • Manufactured in Australia from Safari’s own Industrial Spec UV Stabilised Polyethylene
  • They look identical to the current versions of the Safari Snorkel
  • They have a Life Time warranty*
  • They primarily suit current model vehicles.
Safari Snorkel Kit - V-SPEC. BT-50 UP-UR models. Only fits P5-AT engines.

SAFARI SNORKEL INSTALLATION GUIDE | SS985HF

Specifications

  • Fits vehicle year to: 2019
  • Fits vehicle year to month: 12
  • Fits vehicle year from: 2011
  • Fits vehicle year from month: 11
  • Style: V-SPEC
  • Model: SS985HF
  • Material type: UV Stabilised Polyethylene
  • Fitment side: Drivers Side
  • Fitting time approx: 2.5 Hr

Vehicle Compatibility Guide

Make Model Series Year From Year To Body Engine Engine Capacity Variant Drivetrain Cylinders
MAZDA BT-50 UP 2011 2019 Ute P5-AT 3.2L MZ-CD 5
MAZDA BT-50 UP 2011 2019 Cab Chassis P5-AT 3.2L MZ-CD 5
MAZDA BT-50 UP 2011 2019 Cab Chassis P5AT 3.2L XT Manual 5
MAZDA BT-50 UP 2011 2019 Cab Chassis P5AT 3.2L XT, XTR FREESTYLE Auto/Manual 5
MAZDA BT-50 UP 2011 2019 Cab Chassis P5AT 3.2L XT Manual 5
MAZDA BT-50 UP 2011 2019 Ute P5AT 3.2L GT, XT, XTR Auto/Manual 5
MAZDA BT-50 UP 2011 2019 Ute P5AT 3.2L XT, XTR Auto/Manual 5
MAZDA BT-50 UP 2011 2019 Cab Chassis P5AT 3.2L XT FREESTYLE CAB 5
MAZDA BT-50 UP 2011 2019 Cab Chassis P5AT 3.2L XT FREESTYLE CAB 5
MAZDA BT-50 UP 2011 2019 Ute P5AT 3.2L XTR FREESTYLE CAB 5
MAZDA BT-50 UP 2011 2019 Cab Chassis P5AT 3.2L XT Manual 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT FREESTYLE CAB 5
MAZDA BT-50 UR 2011 2019 Ute P5AT 3.2L XT, XTR 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT FREESTYLE CAB 5
MAZDA BT-50 UR 2011 2019 Ute P5AT 3.2L XT, GT, XTR 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT 5
MAZDA BT-50 UR 2011 2019 Ute P5AT 3.2L XTR FREESTYLE CAB 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT FREESTYLE CAB 5
MAZDA BT-50 UR 2011 2019 Ute P5AT 3.2L XT, XTR 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT FREESTYLE CAB 5
MAZDA BT-50 UR 2011 2019 Ute P5AT 3.2L XT, GT, XTR 5
MAZDA BT-50 UR 2011 2019 Cab Chassis P5AT 3.2L XT 5
MAZDA BT-50 UR 2011 2019 Ute P5AT 3.2L XTR FREESTYLE CAB 5



Safari Snorkel Mazda BT-50 4x4 Kit - Parts List

Mazda BT-50 4WD Snorkel for 08/2011 Onwards 3.2L Diesel Models - Safari Automotive Mazda BT-50 4x4 Snorkel Part Number SS985HF

ITEM PART NO.
 DESCRIPTION
 QTY
1 685-133-000 BODY - SNORKEL (SS985HF) 1
2 000-135-800 3 ½" AIR RAM ASSEMBLY 1
3 685-032-000 BRACKET - UPPER MOUNTING 1
4 000-002-100 BOLT - HEX - 6mm x 1.0 x 14mm (SEMS) 2
5 000-951 SCREW - S/T - 4.2mm x 13mm - S/S 3
6 000-960 INSERT - PLASTIC 3
7 000-110 STUD - 8mm x 1.25 x 25mm - S/S 4
8 000-311-300 WASHER - BODY - 8mm x 30mm - S/S 4
9 000-205-300 NUT - NYLOC - 8mm x 1.25mm - S/S 4
10 685-024-000 HOSE - AIR ENTRY 1
11 000-908 CLAMP - HOSE - 70/90mm 1
12 000-1911 CLAMP - HOSE 100/120mm 1
13 000-914/B CLAMP - HOSE - SIZE 56 (BLACK) 1
14 685-017-000 TEMPLATE - GUARD PANEL 1
